關鍵詞： 電動 新型 釬探機
ABSTRACT
In accordance with China's building codes, the vast majority of construction projects based on the Turkish side to the bottom after excavation carried out geological exploration, the general said solder detectors, to determine the basis of certain geological, uniformity depth, to see whether there is a local soft or too tough Geological conditions, in order to deal with in the foundation. Ever exploration of the solder used artificial way, but the presence of the high cost of exploration brazing, slow, not standards, unequal power, and many other shortcomings, and the majority of workers often meet up, will not achieve due results.
The design of new electrical solder exploration of the biggest advantages is the design of new, small size, light weight, compact, heavy hammer will, hammerhead natural whereabouts, no other human factors, transportation convenient, shift-fast, safe, reliable, easy maintenance , simple operation, one will see. A single-phase power, efficiency is of a more than five times the solder, saving a lot of resources and cost effectively shorten the construction period.
Exploration of new electrical solder machine has three main components: the electromagnetic hammer, and with self-locking of the foot. The course of their work are as follows: The chassis-placed to secure exploration and vertical with the ground, and then solder used hammers hammering exploration devices at the head of the hammer to a certain depth, and record the number of hammering, the final use of the equipment from the solder Exploration - Uprooted from the ground, completed a solder exploration work, then move to the next-filler for exploration solder points followed by brazing exploration.
KEY WORDS：electromotion new type solder Exploration
目錄
第一章 前言 1
1.1釬探機的常識和技術現狀 1
1.2人工釬探與釬探機的優缺點 1
1.3釬探機的市場前景 2
1.4釬探機工作過程和機械構造 3
1.5釬探的工藝標準 4
第二章 總體設計 8
2.1概述 8
2.2設計任務 8
2.3設計目的 9
2.4設計方案選擇 9
2.5設計題目分析及設計思想 10
2.6設計主參數及機構類型確定 11
第三章 主要部件設計 12
3.1電磁錘設計 12
3.2鎖釬器設計 20
第四章 輔助部件設計 28
4.1底架設計 28
4.2控制系統設計 37
第五章 釬探機的使用 38
5.1釬探機使用前的準備 38
5.2釬探機的使用 38
5.3釬探機的調整 38
